Pigment Ultramarine Blue (Pigment Blue 29)

For improving the elegance and performance of plastics, colours play an important role. From the beginning, organic as well as inorganic pigments are used for colouration of plastics due to its excellent properties.

  • Compatibility with all kinds of polymers
  • Easy dispersion
  • Maintenance of polymer’s dimensional stability
  • Heat fastness
  • Light and weather fastness
  • Opacity
  • Insolubility, avoiding migration tendencies

All the inorganic pigments are generally safe and environment safe except some cases.

Colour Index Name ULTRAMARINE BLUE
Colour Index No 77007
Chemical Class Sodium Alumino Sulphosilicate
Molecule Weight 994.5
C. A. S. NO. 57455-37-5
Molecular Formula Al 6 Na 8 O 24 S 3 Si 6

Physical Properties :

Oil Absorption 30-35%
Tap Density 0.50-0.60 (g/cm3 )
Specific Gravity ( 20 C ) 2.00-2.50 at 200 c
Solubility in Water Maximum 1 %
Particle Size 1.00-1.50 (μm)
Heat Stability Stable up to 350o C: As per Application

Fastness Properties : ( 1-5 Scale : 1= Poor, 5= Excellent )

Water 5 Toluene 4.5
Ethenol 5 MEK 5
Butanol 5 Mineral Turpentine 5
Acetone 5 Soap 5
Butyl Acetate 5 Wax 5
Methanol 5 Alkalies NaOH 5
Cellosolve 5 Acids ( HCL) 5
Ortho- xylene 4.5 Sterilization 5

Oil/ Plasticizer( 1-8 Scale : 1= Poor, 8= Excellent ) :

Light Fastness 8
Linseed Oil, Caster Oil, DCO 8
DOP, DBP 8
Molecular Weight 1058
C. A. S. NO. 1328 - 53-6
Molecular Formula C 32 H 2 Cl 14 N 8

Application :

  • Plastic-PP/LDPE/PVC
  • Rubber Products
